Specification:

Sealing Mechanism: - Welded Bellows

Material Exposed to Vacuum: - Stainless steel.

Bakeout Temperature: - 200°C

Operating Temperature: - -20°C to 150°C

Pressure Range: - Atmosphere to 1 x 10⁻¹¹ Torr

Position Lock: - Thumb Screw

Maximum Torque: - 7.81 lbs. / in.

Scale Resolution: - 5°
